Outdoor P10 SMD Main Parameter Unit Module ItemParameterModel NumberP10-4SModule size320mm*160mmPixel pitch10mmPixels Density10000 dots/m²Pixel configuration1R1G1BPackage modeSMD3535Pixel resolution32dots(W)*16 dots(H)Drive typeConstant drive (MBI5124/2038s)Scan mode 1/4scanPort typeHUB75Brightness of white balance≥7500cd/m²Best viewing distance³10mBest viewing distance160°(W) 120°(H)Temperaturestorage:-35℃～+85℃ working:-20℃～+50℃Operation humidity10%-95%Thickness80mmPowerWorking voltageAC220V±10%Average Power consumption210W/㎡

Outdoor P5 SMD Main Parameter Unit ModuleItemParameterModel NumberP5-8SModule size320mm*160mmPixel pitch5mmPixels Density40000 dots/m²Pixel configuration1R1G1BPackage modeSMD2727Pixel resolution64dots(W)*32 dots(H)Drive typeConstant driveScan mode1/8scanPort type75-ABrightness of white balance≥6000cd/m²Best viewing distance5M～20MBest viewing distance160°(W) 120°(H)Temperature storage:-35℃～+85℃ working:-20℃～+50℃Relative humidity10%-95%Thickness85mmPowerWorking voltageAC220V±10%Average Power consumption580W/S

Outdoor P8 Main Technical ParameterNo.ItemParameter1Pixel pitchP8-4S2Package modeSMD35353Pixel wafer composed1R1G1B4Module size256mm*128mm5Pixel resolution32dots(W)*16 dots(H)6Pixel density15625 dots/m27Scan mode1/48Drive modeConstant drive9Port typeHUB 7510Power RequirementsAC220V±10% ,50Hz11Environmental requirements-5℃- +45℃   35%--85%RH12Environmental requirements-40℃- +50℃  35%--85%RH13visual angleHorizon 110degree，vertical 4degree14Visible distance³10m15Brightness≥5000cd/m216Entire screen flatness＜1mm17（W/m2）Largest , average power600/300
